Marcel Piping is supreme quality Threaded Nipple Manufacturers and supplier of Threaded Pipe Nipples, complete piping solutions for small fabrication jobs as well as turnkey projects. We can manufacture One End Threaded Pipe Nipple as per customer specifications and also in accordance with international standards. Pipe Nipples are offered in various grades, including stainless steel (304, 304L, 316, 316L, 904L), carbon steel, aluminium, brass, copper, cupro nickel, nickel alloys and alloy steel in both seamless and welded form.Threaded Pipe Nipple Dimensions in accordance with ASME B16.11 / BS 3799, as per B16.11 standard covers pressure-temperature ratings, dimensions,marking, tolerances and material requirements.
Metric Threaded Pipe Nipple is a fitting, consisting of a short piece of pipe, usually provided with a male pipe thread at each end, for connecting two other fittings. We manufacture a range of pipe nipples such as female threaded pipe nipple, close threaded pipe nipple, BSP threaded pipe nipple, NPT pipe nipples. Threaded Pipe nipples are available in sizes ranging from 1/8” to 4” and can be fabricated and polished as per customer specifications.
Dimensions : ASME 16.11, MSS SP-79, MSS SP-95, 83, 95, 97, BS 3799
Class : 3000 LBS, 6000 LBS, 9000 LBS
Type : Threaded (S/W) & SCREWED (SCRD) – NPT, BSP, BSPT
ASME 16.11, MSS SP-79, MSS SP-95, 83, 95, 97, BS 3799
DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
ASME B16.11 Stainless Steel Forged Threaded Pipe Nipple :
ASTM A182 F304, F304L, F306, F316L, F304H, F309S, F309H, F310S, F310H, F316TI, F316H, F316LN, F317, F317L, F321, F321H, F11, F22, F91, F347, F347H, F904L, ASTM A312/A403 TP304, TP304L, TP316, TP316L
Duplex & Super Duplex Steel ASME B16.11 Forged Threaded Pipe Nipple :
ASTM A 182 – F 51, F53, F55 S 31803, S 32205, S 32550, S 32750, S 32760, S 32950.
Carbon Steel ASME B16.11 Forged Threaded Pipe Nipple:
ASTM/ ASME A 105, ASTM/ ASME A 350 LF 2, ASTM / ASME A 53 GR. A & B, ASTM A 106 GR. A, B & C. API 5L GR. B, API 5L X 42, X 46, X 52, X 60, X 65 & X 70. ASTM / ASME A 691 GR A, B & C
ASME B16.11 Alloy Steel Forged Threaded Pipe Nipple:
ASTM / ASME A 182, ASTM / ASME A 335, ASTM / ASME A 234 GR P 1, P 5, P 9, P 11, P 12, P 22, P 23, P 91, ASTM / ASME A 691 GR 1 CR, 1 1/4 CR, 2 1/4 CR, 5 CR, 9CR, 91
ASME B16.11 Copper Alloy Steel Forged Threaded Pipe Nipple: ASTM / ASME SB 111 UNS NO. C 10100 , C 10200 , C 10300 , C 10800 , C 12000, C 12200, C 70600 C 71500, ASTM / ASME SB 466 UNS NO. C 70600 ( CU -NI- 90/10) , C 71500 ( CU -NI- 70/30)
Nickel Alloy Forged Threaded ASME B16.11 Pipe Nipple:
ASTM / ASME SB 336, ASTM / ASME SB 564 / 160 / 163 / 472, UNS 2200 (NICKEL 200) , UNS 2201 (NICKEL 201 ) , UNS 4400 (MONEL 400 ) , UNS 8020 ( ALLOY 20 / 20 CB 3 ) , UNS 8825 INCONEL (825) , UNS 6600 (INCONEL 600 ) , UNS 6601 (INCONEL 601) , UNS 6625 (INCONEL 625) , UNS 10276 (HASTELLOY C 276)
AFRICA
Nigeria
Algeria
Angola
Tanzania
Libya
Egypt
Sudan
Equatorial Guinea
The Republic Of Congo
Gabon
NORTH AMERICA
Usa
Canada
Mexico
Costa Rica
Trinidad And Tobago
Jamaica
Denmark
MIDDLE EAST ASIA
Saudi Arabia
Iran
Iraq
Uae
Qatar
Bahrain
Oman
Kuwait
Turkey
Jordan
SOUTH AMERICA
Argentina
Bolivia
Brazil
Chile
Venezuela
Colombia
Ecuador
Guyana
Paraguay
Uruguay
EUROPE
Norway
Germany
France
Italy
Uk
Spain
Netherland
Belgium
Greece
Czech Republic
Portugal
Hungary
SOUTH AFRICA
ASIA
India
Singapore
Malaysia
Indonesia
Thailand
Vietnam
South Korea
Japan
Sri Lanka
Maldives
Bangladesh
Mayanmar
Taiwan
Cambodia
© 2018. The content on this website is owned by Registrant of domain www.marcelpiping.com.Design and Developed By www.mesotek.com
a technical knowledge base for all the process piping professionals around the world...
by TheProcessPiping · Published August 14, 2018 · Updated August 6, 2018
In piping, a nipple is a fitting, consisting of a short piece of pipe, usually provided with a male pipe thread at each end, for connecting two other female threaded fittings or pipes. Pipe Nipples are commonly used as adapters from one connection type to another. Pipe nipples are mainly used in low-pressure piping systems.
Pipe nipples are manufactured by cutting a specified length of pipe and applying the desired end connections. The pipe nipple dimensions and material follow from pipe specifications. Similar to pipe, pipe nipples also come in either a seamless or welded construction.
When ordering pipe nipples, the following properties must be specified:
The length of pipe nipple is usually specified by the overall length including threads. Pipe Nipples can come in any specified length, but most commonly range between close to 12”. A close pipe nipple is the shortest piece of pipe necessary to allow for fully threaded end connections, where there is no smooth surface between threads.
There are several different types of pipe nipples in common use. A short list includes:
In its most basic form, a pipe nipple is a short length of pipe with male pipe threads at both ends for connecting other fittings. Generally there is a short distance of unthreaded pipe between the two threaded ends, depending on how far apart you need the attached fittings to be. When there is no unthreaded pipe between the two connecting ends, the pipe nipple is called a “close nipple” or a “running nipple”. In that case, connected fittings come close to touching one another and very little of the nipple can be seen.
Close nipples are difficult to work with. A close nipple can only be unscrewed by gripping one threaded end with a pipe wrench which will damage the threads and necessitate replacing the nipple, or by using a specialty tool known as a nipple wrench which grips the inside of the pipe, leaving the threads undamaged.
In pipe nipples where there is a little space between both the threaded ends, there may have a hexagonal section in the center for a wrench to grasp the nipple. These nipples are called as “hexagonal nipple”. This hexagonal section in the middle functions like a nut that can be gripped by a normal wrench, providing a greater mechanical advantage than normal rounded pipe nipple. A hexagonal nipple with more distance between the threaded ends is called a “long hex nipple”.
For ping systems which require a change in pipe dimension, “reducing nipple” or “unequal nipple” is used. Reducing nipple takes a female fitting with a larger connection and attaches it to a smaller one. Care should be taken when using these parts since a reduction in pipe diameter can mean more pressure and greater flow rate in the smaller pipe/fitting.
For piping systems which require pipe connection to tubing, “hose nipple” is used. Hose nipple features a male threaded connection on one end and a hose barb on the other end. The hose barb may be the same size as the pipe connection or it may be of reduced size.
For piping systems which requires to be connected to welded pipes or fittings, “welding nipple” is used. Welding nipple has a threaded connection on one end and normal cut pipe at the other end. The unthreaded end of the pipe provides more surface area for the use of welding materials to make the stronger connection. One main benefit of welding nipple is that once the unthreaded end is connected, connecting pipes or other fittings to the threaded end becomes much more easy.
The end connections need to be specified by the customer as well;
Plain Both Ends (PBE), Threaded Both Ends (TBE), Beveled Both Ends (BBE), Threaded One End (TOE), Beveled One End (BOE), Plain One End (POE) or a combination thereof, depending on the ends of the piping system into which the pipe nipple will be fitted.
A Plain Both Ends (PBE) pipe nipple, has both the ends as plain ends, with no thread, typically used to fit a socket weld connection.
A Threaded Both Ends (TBE) pipe nipple has both the ends as threaded ends and used to fit female threaded connections.
A Beveled Both Ends (BBE) pipe nipple has both the ends as bevel ends and is used for welding purposes similar to a buttweld fitting.
What do you think about the above article – informative or needs improvements? What are further types of pipe nipples commonly used in piping industry? Any question or query about pipe nipple in your mind? Share your feedback and experience in the comment box below for making this article more meaningful.
