COLOR * TEXT * GRAPHICS * ANIMATION * VIDEO
Imagine being able to change color, create patterns and move them along a tube. Now you can with the aptly named DMX TUBE®. Instead of neon or fluorescent, an array of LEDs fills each tube. It looks like neon or fiber optics, yet it does much more.
The DMX TUBE® instantly comes to life with flowing, fading, chasing and ebbing streams of colored light. Custom patterns run automatically or are triggered from existing control systems. Visual effects that were previously impossible are now simple to create and control.
Each section contains individually controllable pixels comprised of red, green, and blue LEDs. Pixels can be uniform for a solid color effect or different to create color patterns. Color patterns can move at varying speeds and continue through linked units.
The DMX TUBE® enables direct DMX input for professional programming and control of vibrant color patterns and dynamic visual effects.
The DMX TUBE® lighting effect is powered by LED technology which offers:
Ultra-long lamp life
Minimal maintenance
Low heat emission, No UV and IR
Low power consumption
Easy installation
The LED DMX Tube is a graphics and color changing grade tub that can be set to 1. 2. 4, 8, and 16 pixels per tube. LED DMX Tubes come in half meter (500mm) and 1 meter versions.The LED DMX Tube uses the very latest in high quality (RGB) LED's to provide high luminosity even and consistent colors.The LED DMX Tube can be directly controlled b DMX-512, PC Graphics Control,or a stand-alone graphics playback systems.
ADVERTISING * PROMOTION * ARCHITECTURAL * DISPLAY * ENTERTAINMENT * RETAIL * SIGNAGE
LED environment-friendly long life light source
Advanced RGB color-mixing technology
Energy efficiency (maximum 16.8 W per meter)
Resistance to direct sunlight
Intelligent control system for lighting effects
No additional power or control boxes required with the unique built-in power + data unit
Intelligent auto-protect function
Durable enclosures made of selected materials
Virtually no gap when units are butted end to end
Voltage: Line voltage: AC 100 V - 240 V; Inside power supply :12 v
Number of LEDS: 144 ultrabright bulbs
LED bulbs: RGB color mixing (48 Red, 48 Green, 48 Blue) with 4 or 8 separate sections per color
Controlling mode: dynamic or static
Control: DMX512 in DMX mode or dedicated controller.
Individual Control: SRC-236DL controller
Computer Control: PC + SRC-236DL controller
DMX Controller: Universal DMX 512 controller
Signal Input Connector: 5 pin male connector
Signal Output Connector: 5 pin female connector
Colors: red, yellow, white, purple, cyan, green, blue or changeable
Color change: RGB color mixing, solid state, no motors!
Roll Chase 1 (rolling backward and forward)
Roll Chase 2 (scan backward and forward)
Brightness: Red: 700-1300 mcd; blue: 465-474 mcd; green: 1500-3000 mcd
Wavelength: Red: 625-640 nm; Blue: 465-474 nm; Green: 515-524
Working environmental temperature: -40 C to 80 C (-4 to 140 degrees F)
Tube composition: clear or milky white optically diffused polycarbonate (PVC)
Installing Methods: 1. channels screws into installed brackets 2. channels snaps into installed bracket
Signal Amplifier: already set inside the tube
Power Supply: already set inside the tubes
Recommended DMX Tubes to design In:
1. Mounting surface
2. Mounting plate
3. Fixing plates
4. DMX Tube
The DMX Tube is mounted as shown below. The mounting plate (2) is attached to the surface to be mounted(1). The DMX Tube (4) is placed against the mounting plate (2) and secured by the fixing plates (3).
Suggestions: Please install the same way as these diagrams and the diagrams located in your products user manual. After the connectors are joined together, the female connector should be on top and the male connector at bottom to improve the waterproofing effect.
End view (solid line) and Side view(dashed line) (candelas)
Connection Variations (Control Type Dependent)
PC or Stand-alone Matrix Connection
PC or Stand-alone Matrix Connection
This configuration requires the additonal hardware listed below:
SRC-236DL Controller-or- SRC-236DL Controller and PC SDL-109A-T1(Quantity based on total number of tubes)
Example 2:
DMX-512 Control
This configuration requires the additional haredware listed below:
Standard DMX-512 Controller
SDL-109A-T1 (Quantity based on total number of tubes.)
LED DMX Tube is an intelligent fixture and under certain configurations requires external controllers and signal amplifiers for their operation and installation.
As Illustrated above: 2 sections per tube, 16 pixels per tube, 3 channels per pixel, 48 channels per tube
Use the SRC-236DL Ver1.2 Controller to write the DMX address into the tube memory by connecting the controller to the first tube. With all tubes connected assign in the controller menu the start address of the first tube and follow the instructions in the user manual to complete the write to memory process. One DMX Universe equals 10 tubes. Only 1 DMX Universe can be used in Standard DMX mode per 10 tubes. Once the memory has been written and the dmx addresses assigned you can connect a standard DMX controller to thee tube matrix via the 5-pin DMX connector. To use more tuves in 48 channel mode a PC and PC Software in conjunctionwith the SRC-236DL ver1.2
DUE TO CONTINUOUS IMPROVEMENTS, SPECIFICATIONS MAY CHANGE WITHOUT PRIOR NOTICE.
