This article explains how to use LaTeX to create and customize tables: changing size/spacing, combining cells, applying colour to rows or cells, and so forth.
We can start with one of the simplest examples of a table:
\begin{center}
\begin{tabular}{ c c c }
cell1 & cell2 & cell3 \\
cell4 & cell5 & cell6 \\
cell7 & cell8 & cell9
\end{tabular}
\end{center}
The tabular environment is the default LATEX method to create tables. You must specify a parameter to this environment; here we use {c c c} which tells LaTeX that there are three columns and the text inside each one of them must be centred.
The tabular environment provides additional flexibility; for example, you can put separator lines in between each column:
\begin{center}
\begin{tabular}{ |c|c|c| }
\hline
cell1 & cell2 & cell3 \\
cell4 & cell5 & cell6 \\
cell7 & cell8 & cell9 \\
\hline
\end{tabular}
\end{center}
Here is a description of the constructions used in the example above:
Below you can see a second example which uses various vertical and horizontal lines (often called "rules"):
\begin{center}
\begin{tabular}{||c c c c||}
\hline
Col1 & Col2 & Col2 & Col3 \\ [0.5ex]
\hline\hline
1 & 6 & 87837 & 787 \\
\hline
2 & 7 & 78 & 5415 \\
\hline
3 & 545 & 778 & 7507 \\
\hline
4 & 545 & 18744 & 7560 \\
\hline
5 & 88 & 788 & 6344 \\ [1ex]
\hline
\end{tabular}
\end{center}
When formatting a table you might require a fixed length either for each column or for the entire table. The following example adds the array package to document preamble:
and uses it to set fixed column widths:
\documentclass{article}
\usepackage{array}
\begin{document}
\begin{center}
\begin{tabular}{ | m{5em} | m{1cm}| m{1cm} | }
\hline
cell1 dummy text dummy text dummy text& cell2 & cell3 \\
\hline
cell1 dummy text dummy text dummy text & cell5 & cell6 \\
\hline
cell7 & cell8 & cell9 \\
\hline
\end{tabular}
\end{center}
\end{document}
In the tabular environment, the parameter m{5em} sets a length of 5em for first column (1cm for the other two) and centres the text in the middle of the cell. The aligning options are m for middle, p for top and b for bottom. When using these parameters the text is automatically formatted to fit inside each cell.
If you don't need to control the width of each cell, but of the entire table and then evenly distribute the space within, use the tabularx package. See the example below:
\documentclass{article}
\usepackage{tabularx}
\begin{document}
\begin{tabularx}{0.8\textwidth} {
| >{\raggedright\arraybackslash}X
| >{\centering\arraybackslash}X
| >{\raggedleft\arraybackslash}X | }
\hline
item 11 & item 12 & item 13 \\
\hline
item 21 & item 22 & item 23 \\
\hline
\end{tabularx}
\end{document}
The environment tabularx is similar to tabular but more flexible, To use it, add the line \usepackage{tabularx} to the document preamble. Notice that the environment opening statement is different, in the example the table width is set to 0.8\textwidth, which is 80% of the document's text width. You can use any of the LATEX units to set this length.
The prefix inside braces | >{\raggedright\arraybackslash}X | >{\centering\arraybackslash}X | >{\raggedleft\arraybackslash}X | sets the alignment of each column: the first one to left, the second one to center and the third one to right.
Rows and columns can be merged to create larger table cells. The following example uses the \multicolumn command to merge several columns:
\documentclass{article}
\usepackage{multirow}
\begin{document}
\begin{tabular}{ |p{3cm}||p{3cm}|p{3cm}|p{3cm}| }
\hline
\multicolumn{4}{|c|}{Country List} \\
\hline
Country Name or Area Name& ISO ALPHA 2 Code &ISO ALPHA 3 Code&ISO numeric Code\\
\hline
Afghanistan & AF &AFG& 004\\
Aland Islands& AX & ALA &248\\
Albania &AL & ALB& 008\\
Algeria &DZ & DZA& 012\\
American Samoa& AS & ASM&016\\
Andorra& AD & AND &020\\
Angola& AO & AGO&024\\
\hline
\end{tabular}
\end{document}
Let's review each component of the command \multicolumn{4}{|c|}{Country List} \\:
To combine rows you need to add the multirow package to your document preamble:
You can then use the \multirow command in your document:
\documentclass{article}
\usepackage{multirow}
\begin{document}
\begin{center}
\begin{tabular}{ |c|c|c|c| }
\hline
col1 & col2 & col3 \\
\hline
\multirow{3}{4em}{Multiple row} & cell2 & cell3 \\
& cell5 & cell6 \\
& cell8 & cell9 \\
\hline
\end{tabular}
\end{center}
\end{document}
The multirow command takes three parameters; our example uses the following settings:
If you have to insert a very long table, which takes up two or more pages in your document, use the longtable package. First, add the following line to your document preamble:
You can then use the longtable environment, as shown in the following example:
\documentclass{article}
\usepackage{longtable}
\begin{document}
\begin{longtable}[c]{| c | c |}
\caption{Long table caption.\label{long}}\\
\hline
\multicolumn{2}{| c |}{Begin of Table}\\
\hline
Something & something else\\
\hline
\endfirsthead
\hline
\multicolumn{2}{|c|}{Continuation of Table \ref{long}}\\
\hline
Something & something else\\
\hline
\endhead
\hline
\endfoot
\hline
\multicolumn{2}{| c |}{End of Table}\\
\hline\hline
\endlastfoot
Lots of lines & like this\\
Lots of lines & like this\\
Lots of lines & like this\\
Lots of lines & like this\\
Lots of lines & like this\\
Lots of lines & like this\\
Lots of lines & like this\\
Lots of lines & like this\\
...
Lots of lines & like this\\
\end{longtable}
The behaviour of longtable is similar to the default tabular, but generates tables that can be broken by the standard LATEX page-breaking algorithm. There are four longtable-specific elements:
Positioning a table is easy if they're inside a float table environment.
\documentclass{article}
\begin{document}
Below is a table positioned exactly here:
\begin{table}[h!]
\centering
\begin{tabular}{||c c c c||}
\hline
Col1 & Col2 & Col2 & Col3 \\ [0.5ex]
\hline\hline
1 & 6 & 87837 & 787 \\
2 & 7 & 78 & 5415 \\
3 & 545 & 778 & 7507 \\
4 & 545 & 18744 & 7560 \\
5 & 88 & 788 & 6344 \\ [1ex]
\hline
\end{tabular}
\end{table}
\end{document}
The parameter h! passed to the table environment declaration establishes that this table must be placed here, and override LATEX defaults. The positioning parameters that can be passed-in include:
For further examples on table positioning see the Positioning images and tables article.
In this example there are a few more commands:
Tables can be captioned, labelled and referenced by means of the table environment.
\documentclass{article}
\begin{document}
Table \ref{table:1} is an example of a referenced \LaTeX{} element.
\begin{table}[h!]
\centering
\begin{tabular}{||c c c c||}
\hline
Col1 & Col2 & Col2 & Col3 \\ [0.5ex]
\hline\hline
1 & 6 & 87837 & 787 \\
2 & 7 & 78 & 5415 \\
3 & 545 & 778 & 7507 \\
4 & 545 & 18744 & 7560 \\
5 & 88 & 788 & 6344 \\ [1ex]
\hline
\end{tabular}
\caption{Table to test captions and labels.}
\label{table:1}
\end{table}
\end{document}
There are three important commands in the example:
To create a list of tables use the \listoftables command. The caption of each table will be used to generate this list. For languages supported by the babel package, the title "List of tables" will be translated accordingly. See the article about International language support for more info.
\documentclass{article}
\begin{document}
\listoftables
\vspace{5pt}
The table \ref{table:1} is an example of referenced \LaTeX{} elements.
\begin{table}[h!]
\centering
\begin{tabular}{||c c c c||}
\hline
Col1 & Col2 & Col2 & Col3 \\ [0.5ex]
\hline\hline
1 & 6 & 87837 & 787 \\
2 & 7 & 78 & 5415 \\
3 & 545 & 778 & 7507 \\
4 & 545 & 18744 & 7560 \\
5 & 88 & 788 & 6344 \\ [1ex]
\hline
\end{tabular}
\caption{This is the caption for the first table.}
\label{table:1}
\end{table}
\begin{table}[h!]
\centering
\begin{tabular}{||c c c c||}
\hline
Col1 & Col2 & Col2 & Col3 \\ [0.5ex]
\hline\hline
4 & 545 & 18744 & 7560 \\
5 & 88 & 788 & 6344 \\ [1ex]
\hline
\end{tabular}
\caption{This is the caption for the second table.}
\label{table:2}
\end{table}
\end{document}
Several table elements can be modified to suit the needs of your document. Below you will learn how to modify the line thickness, the line colour and the background colour of the cells in your table.
The legibility of a table can sometimes be improved by incrementing the column spacing and row stretch.
\documentclass{article}
\setlength{\arrayrulewidth}{0.5mm}
\setlength{\tabcolsep}{18pt}
\renewcommand{\arraystretch}{1.5}
\begin{document}
\begin{tabular}{ |p{3cm}|p{3cm}|p{3cm}| }
\hline
\multicolumn{3}{|c|}{Country List} \\
\hline
Country Name or Area Name& ISO ALPHA 2 Code &ISO ALPHA 3 \\
\hline
Afghanistan & AF &AFG \\
Aland Islands & AX & ALA \\
Albania &AL & ALB \\
Algeria &DZ & DZA \\
American Samoa & AS & ASM \\
Andorra & AD & AND \\
Angola & AO & AGO \\
\hline
\end{tabular}
\end{document}
A description of the commands is provided below:
You can apply alternating colours to the rows of your table by using the xcolor package with the table option, as demonstrated in the following example:
\documentclass{article}
\usepackage[table]{xcolor}
\setlength{\arrayrulewidth}{0.5mm}
\setlength{\tabcolsep}{18pt}
\renewcommand{\arraystretch}{2.5}
\begin{document}
{\rowcolors{3}{green!80!yellow!50}{green!70!yellow!40}
\begin{tabular}{ |p{3cm}|p{3cm}|p{3cm}| }
\hline
\multicolumn{3}{|c|}{Country List} \\
\hline
Country Name or Area Name& ISO ALPHA 2 Code &ISO ALPHA 3 \\
\hline
Afghanistan & AF &AFG \\
Aland Islands & AX & ALA \\
Albania &AL & ALB \\
Algeria &DZ & DZA \\
American Samoa & AS & ASM \\
Andorra & AD & AND \\
Angola & AO & AGO \\
\hline
\end{tabular}
\end{document}
Notice the braces right before the command
\rowcolors{3}{green!80!yellow!50}{green!70!yellow!40}
and after the tabular environment. The command \rowcolors takes three parameters each passed inside braces:
See the xcolor package documentation (at the further reading section) for a list of available colours and how to create your own. In the example the colours green and yellow are mixed in different proportions.
For the command to work make sure to add
to the preamble of your LATEX file.
All elements in a table can be customized to use a specific colour. Again, this functionality is provided by xcolor so you must add
to the preamble. Below you can see an example.
\documentclass{article}
\usepackage[table]{xcolor}
\setlength{\arrayrulewidth}{1mm}
\setlength{\tabcolsep}{18pt}
\renewcommand{\arraystretch}{2.5}
\newcolumntype{s}{>{\columncolor[HTML]{AAACED}} p{3cm}}
\arrayrulecolor[HTML]{DB5800}
\begin{document}
\begin{tabular}{ |s|p{3cm}|p{3cm}| }
\hline
\rowcolor{lightgray} \multicolumn{3}{|c|}{Country List} \\
\hline
Country Name or Area Name& ISO ALPHA 2 Code &ISO ALPHA 3 \\
\hline
Afghanistan & AF &AFG \\
\rowcolor{gray}
Aland Islands & AX & ALA \\
Albania &AL & ALB \\
Algeria &DZ & DZA \\
American Samoa & AS & ASM \\
Andorra & AD & \cellcolor[HTML]{AA0044} AND \\
Angola & AO & AGO \\
\hline
\end{tabular}
\end{document}
Below is a description about how to change the colour of each element in the table:
\newcolumntype{s}{>{\columncolor[HTML]{AAACED}} p{3cm}}
A brief description of parameters in the tabular environment.
Tables can be created using tabular environment.
the line at the top is aligned with the text baseline
the line at the bottom is aligned with the text baseline
the table is centred to the text baseline
paragraph column with text vertically aligned at the top
paragraph column with text vertically aligned in the middle (requires array package)
paragraph column with text vertically aligned at the bottom (requires array package)
the format form is repeated num times; for example *{3}{|l}| is equal to |l|l|l|
To separate between cells and introducing new lines use the following commands:
start new row (additional space may be specified after \\ using square brackets, such as \\[6pt])
start a new line within a cell (in a paragraph column)
partial horizontal line beginning in column i and ending in column j
Do The Wife Com Free
Code Fuck Pornhub
Net Mature Com
Gallery Outdoor Ass
Malena Morgan Lesbian Threesome
Create LaTeX tables online – TablesGenerator.com
LaTeX Tables Editor
Tables - Overleaf, Online LaTeX Editor
Create LaTeX tables online - chengpengzhao.com
Online table editor for Latex - Truben aka Peder Lång ...
Latex Table Online Tool - [100% Verified]
LaTeX tables - Tutorial with code examples - LaTeX ...
Tutorial - Tables in LaTeX
Online WYSIWYG Tables Editor for LaTeX
Table Convert Online - table to markdown,csv,json,latex ...
Latex Table Online
