Hardware Memory Hole Remapping in the BIOS
Thread starter o_o
Start date Feb 27, 2014
I have Mach Speed MSNV-939 Motherboard and 4 sticks of Corsair Value Select 1 GB DDR Memory. Actually a few months ago one of these sticks went bad, and I replaced it with an identical module. Before that stick went bad, I could see about 3.2 GB RAM on Win XP Pro 32 bit. After the stick went bad, due to the configuration of the motherboard, I was limited to 2 GB. When I got the new/replacement stick (same brand and model no), I cannot get more than 2 GB. I did attempt to go into the BIOS and reduce the DDR speed from Auto (or 166 MHz) to 100 MHz, but I still see only 2 GB in Windows. This Motherboard is limited to 4GB, and all along the BIOS shows the entire 4GB. Memtest also sees 4GB when booted using a USB after adding the replacement stick.
My Problem:
I attempted a fresh install of Windows XP, as well as (separately) Windows 7 on this machine. Both 32 bit. In both cases I can only get only 2GB in the Task Manager. In the Computer Properties though, Windows 7 shows 4 GB but in brackets it adds (2GB usable). These are both fresh installs with the default configuration (no startup flags etc.)
I then went into the BIOS and ENABLED H/W Memory Home Remapping. I did not change anything else. (DDR Speed was set to Auto).
Doing this resulted in 2.25 GB for both Widows XP and Windows 7. Why the extra 0.25GB? I thought for 32 Bit Windows, Remapping in the BIOS puts a large chunk of the RAM over the 4GB limit, so a 32 Bit OS would not see it. But here my experience is the opposite.
Id appreciate any clues.
Thank you in advance,
O. O.
You replaced with an identical stick but 'due to the configuration of the motherboard' you are limited to 2GB. I think this is the where you'd need to investigate. If the stick were identical, but you are now limited to 2GB, then something in your BIOS changed, otherwise the stick is not identical.
Your not disclosing enough information about diagnostics. Are you using dual channel?
What happens when two modules only are used, an original module paired with the new one.
Create a table showing the results of testing the various modules/sticks :
- Single Channel:
+ Each stick individually
+ Two Sticks in pair (one original with one old) in primary slots
- Dual Channel
+ Two original sticks paired in primary slots
+ Two sticks, one original and the new one paired in primary slots
Depending on what has happened, expand the above testing to include suitable combinations including the secondary memory slots
You could have something as simple as two memory modules which wont pair when placed in the secondary memory, but might work in the primary slots.
Ensure that memory voltage is set at specification and if possible raise it one notch (lowest allowed fraction; eg, + 0.050 volt).
Dear razel & C1,
Thank you for responding. Sorry for the delay.
C1, yes you are correct, I have not exhaustively tested each stick of RAM. However all 4 sticks are recognized in the BIOS, in CUP-Z and in MemTest, and MemTest passes. If I boot the machine using Puppy Linux on a USB, I can see all 4GB in /proc/meminfo.
Now this is weird:
I thought Windows 32 bit (XP or 7), limits the memory to 4GB, and this includes the Graphic Cards, Network Cards, Sound Cards etc. So I decided to pull out as many cards as I could. I then decided to take out the battery of Motherboard for 10 mins (i.e. reset it for sure). I then booted up Windows XP which was previously showing me only 2 GB, and voila, I get 2.75GB!!!
Now the problem: If I restart the machine, then it goes back to 2 GB??? No other changes i.e. a simple restart.
Im still looking for ideas if anyone has a clue.
Thanks again,
O. O.
Nov 20, 2010
2,173
61
91
www.flickr.com
I can't say if this "Enable 4GB of memory on Vista" article applies to you but it may be worth a read: http://www.ocmodshop.com/enable-4gb-of-memory-on-vista/
I was able to use a Full 3GB on a GeForce GA-N7400 that only supported 3GB of DDR running Win7 32-Bit Ultimate and seems to me I had to tweak it out of her to do it. You can Tweek the Kernel to see over 4GB of Ram but all 32-Bit OS's will never use more the 3.4GB's
I also recall some older MB's having a Toggle in BIOS for Memory Mapping both 32 & 64-Bit OS's.
I can't say if this "Enable 4GB of memory on Vista" article applies to you but it may be worth a read: http://www.ocmodshop.com/enable-4gb-of-memory-on-vista/
I was able to use a Full 3GB on a GeForce GA-N7400 that only supported 3GB of DDR running Win7 32-Bit Ultimate and seems to me I had to tweak it out of her to do it. You can Tweek the Kernel to see over 4GB of Ram but all 32-Bit OS's will never use more the 3.4GB's
I also recall some older MB's having a Toggle in BIOS for Memory Mapping both 32 & 64-Bit OS's.
dunno but i do believe 2 sticks of higher capacity always ran better than 4 sticks on those old mem controllers. my first guess would be they are not identical, even if they have the same model number the chips can differ. especialy since your ram is old, i would find it doubtful a replacement would be identical on value series ram.
If your bios has the ability i would look more closely at the Timing and volt settings than the speed seeing as its already at 166 deafult? thats pc2700 speed already... if its on T1, changing it to T2 alone maybe enough to stabilize the difference(if there is any between them).. mind you depending what you use the system for if, IF the only way you eventually get it working is lowering all the settings including ram bus speed, you'l have better performance with just 2gigs anyway.
dunno but i do believe 2 sticks of higher capacity always ran better than 4 sticks on those old mem controllers. my first guess would be they are not identical, even if they have the same model number the chips can differ. especialy since your ram is old, i would find it doubtful a replacement would be identical on value series ram.
Started by uzzi38
Apr 28, 2020
Replies: 6K
Started by TheF34RChannel
Jun 18, 2017
Replies: 13K
Started by Ottonomous
Nov 1, 2019
Replies: 5K
Started by Stuka87
Aug 10, 2021
Replies: 296
Started by AnitaPeterson
Aug 2, 2021
Replies: 28
AnandTech is part of Future plc, an international media group and leading digital publisher. Visit our corporate site.
© Future Publishing Limited Quay House, The Ambury, Bath BA1 1UA.
All rights reserved. England and Wales company registration number 2008885.
This site uses cookies to help personalise content, tailor your experience and to keep you logged in if you register.
By continuing to use this site, you are consenting to our use of cookies.
Updated: 06/30/2020 by Computer Hope
Often, in the computer's BIOS setup under the Advanced Chipset Features, there is an option for Memory Hole at 15M-16M, with the available options of Disabled and Enabled. This setting allows users to enable or disable the 1 MB of memory required by some ISA expansion cards.
Enabling this feature decreases your memory by 1 MB and allow the few ISA cards that require this memory to work on your computer. However, with some motherboards, enabling this feature could also disable all memory above 15 MB and cause other significant issues. Because ISA cards are rarely used today and because many motherboards don't even have an ISA slot on them, we recommend keeping this option at the default setting of Disabled.
Additional information
See our memory definition for further information and related links.
Memory (RAM) help and support.
