Customizing Widgets and Animations in Flutter with Example

Customizing Widgets and Animations in Flutter with Example

🚀Supercharge Your UI: Customizing Widgets and Animations in Flutter (With Code Examples)

Flutter is famous for its "everything's a widget" approach. While the Material and Cupertino widget libraries are vast, Flutter's true power lies in your ability to create custom widgets and design unique animations that differentiate your app.

Learning to customize these building blocks is essential for any developer who aspires to build professional and memorable user interfaces (UIs).

You can read this full story by clicking here!!

Parte 1:Creating Custom Widgets (The Building Block)

A custom widget is simply an encapsulation of one or more pre-existing widgets. This improves code reuse, readability, and makes your application easier to maintain.

🧱 Example: A Reusable Profile Button (ProfileButton)

Instead of building a Row with a CircleAvatar and aTextEvery time a profile needs to be displayed, we create a custom widget.

Code for profile_button.dart:

import 'package:flutter/material.dart';
class ProfileButton extends StatelessWidget {
  // Custom properties defined in the constructor
  final String userName;
  final String imageUrl;
  final VoidCallback onTap;
  const ProfileButton({
    Key? key,
    required this.userName,
    required this.imageUrl,
    required this.onTap,
  }) : super(key: key);
  @override
  Widget build(BuildContext context) {
    return InkWell(
      onTap: onTap,
      child: Padding(
        padding: const EdgeInsets.all(8.0),
        child: Row(
          mainAxisSize: MainAxisSize.min,
          children: [
            CircleAvatar(
              backgroundImage: NetworkImage(imageUrl),
              radius: 20,
            ),
            const SizedBox(width: 10),
            Text(
              userName,
              style: const TextStyle(
                fontSize: 16,
                fontWeight: FontWeight.bold,
              ),
            ),
          ],
        ),
      ),
    );
  }
}

Use in the application (main.dart):

// ... inside the build() method of a widget
ProfileButton(
  userName: 'Alice',
  imageUrl: 'https://ejemplo.com/avatar.jpg', // Replace with a real URL
  onTap: () {
    print('Perfil de Alice pulsado');
  },
),

💡 Why is this important?

Reusability: Use it ProfileButtonin your sidebar, header, or anywhere else without repeating your design code.
Encapsulation: If you decide to change the font or size of your avatar, you only need to modify one file (profile_button.dart).

Parte 2: Custom Animations (Bringing UI to Life)

Animations transform a static UI into a dynamic user experience. Flutter offers two types:

Implicit Animations (Easy): These use widgets like AnimatedContainer, AnimatedOpacity, or AnimatedSize. Simply change a property and the widget animates automatically.
Explicit Animations (Custom): These use AnimationController and Tween for full control over the transition. The AnimatedBuilder widget is the key tool for this.

✨ Example: A Pulsing Container with AnimatedBuilder

We'll create a container that rhythmically changes scale and color, as if it were "pulsing" (useful for status indicators).

codePulsingContainer (requires a StatefulWidget):

import 'package:flutter/material.dart';
class PulsingContainer extends StatefulWidget {
  const PulsingContainer({super.key});
  @override
  State<PulsingContainer> createState() => _PulsingContainerState();
}
class _PulsingContainerState extends State<PulsingContainer>
    with SingleTickerProviderStateMixin {
  late AnimationController _controller;
  late Animation<double> _scaleAnimation;
  late Animation<Color?> _colorAnimation;
  @override
  void initState() {
    super.initState();
    // 1. Initialize the controller for 1 second
    _controller = AnimationController(
      vsync: this,
      duration: const Duration(milliseconds: 1000),
    )..repeat(reverse: true); //
    // 2. Defines the scale animation (Tween)
    _scaleAnimation = Tween<double>(begin: 1.0, end: 1.15).animate(
      CurvedAnimation(parent: _controller, curve: Curves.easeInOut),
    );
    // 3. Defines the color animation (Tween)
    _colorAnimation = ColorTween(
      begin: Colors.blue.shade300,
      end: Colors.blue.shade700,
    ).animate(_controller);
  }
  @override
  Widget build(BuildContext context) {
    // 4. Use AnimatedBuilder to rebuild just the widget
    return AnimatedBuilder(
      animation: _controller,
      builder: (context, child) {
        return Transform.scale(
          scale: _scaleAnimation.value,
          child: Container(
            width: 100,
            height: 100,
            decoration: BoxDecoration(
              color: _colorAnimation.value, // Color animado
              borderRadius: BorderRadius.circular(15),
              boxShadow: [
                BoxShadow(
                  color: _colorAnimation.value!.withOpacity(0.5),
                  blurRadius: 10,
                ),
              ],
            ),
            child: child,
          ),
        );
      },
      child: const Center(
        child: Text('Pulse', style: TextStyle(color: Colors.white)),
      ),
    );
  }
  @override
  void dispose() {
    _controller.dispose();
    super.dispose();
  }
}
