Oct 26, 2012, 8:00 am EDT | 2 min read
From tiny laptop hard drives to beefier desktop models, traditional disk-based hard drives have a very bold warning on them: DO NOT COVER THIS HOLE. What exactly is the hole and what terrible fate would befall you if you covered it?
Today’s Question & Answer session comes to us courtesy of SuperUser—a subdivision of Stack Exchange, a community-drive grouping of Q&A web sites.
Join 425,000 subscribers and get a daily digest of features, articles, news, and trivia.
By submitting your email, you agree to the Terms of Use and Privacy Policy.
On many hard drives, there’s a text warning to “not cover this hole”, sometimes adding that doing so will void the warranty.
What is the purpose of this hole and why would covering it cause damage or increase the likelihood of drive failure?
Thankfully no field studies or warranty voiding were required to solve the mystery.
Image courtesy of SuperUser contributor Oliver Salzburg.
SuperUser contributor music2myear offers some insight into the tiny hole and the importance of leaving it unobstructed:
It allows for equalization of air pressure between the inside and outside of the drive. While it is not a complete pass-through of outside air into the HDD internals, there is a filter inside the hole that allows the air pressure to equalize.
If the drive were completely sealed, operating at altitudes significantly different from those the drive was manufactured and sealed at, it would cause problems and increase the likelihood of catastrophic failures.
This system works in much the same way as the Eustachian tubes that allow our ears internal pressures to equalize, preventing the explosion of our ear drums.
Dennis expands on this explanation by directing us towards the section of Wikipedia dealing with hard drive integrity:
Check out the Wikipedia hard drive entry paying attention to the Integrity section with reference to the “breather hole”:
Hard disk drives require a certain range of air pressures in order to operate properly. The connection to the external environment and pressure occurs through a small hole in the enclosure (about 0.5 mm in breadth), usually with a filter on the inside (the breather filter). If the air pressure is too low, then there is not enough lift for the flying head, so the head gets too close to the disk, and there is a risk of head crashes and data loss. Specially manufactured sealed and pressurized disks are needed for reliable high-altitude operation, above about 3,000 m (9,800 ft).[99] Modern disks include temperature sensors and adjust their operation to the operating environment. Breather holes can be seen on all disk drives—they usually have a sticker next to them, warning the user not to cover the holes.
The mere mention of headcrashes (and the horrible memory of the sounds our last lost-to-head-crash drive made) are more than enough warning for us.
Have something to add to the explanation? Sound off in the the comments. Want to read more answers from other tech-savvy Stack Exchange users? Check out the full discussion thread here.
How-To Geek is where you turn when you want experts to explain technology. Since we launched in 2006, our articles have been read more than 1 billion times. Want to know more?
The Best Free Tech Newsletter Anywhere
By submitting your email, you agree to the Terms of Use and Privacy Policy.

Sign up or log in to view your list.
On many hard drives, there's a text warning to "not cover this hole", sometimes adding that doing so will void the warranty.
What is the purpose of this hole and why would covering it cause damage or increase the likelihood of drive failure?
oKtosiTe
oKtosiTe 8,500●99 gold badges●4343 silver badges●6969 bronze badges
Breakthrough
33.4k●99 gold badges●101101 silver badges●147147 bronze badges
I especially appreciate that you took a picture of a MacBook Pro where the ribbon cable to the front infrared board and sleep sensor generally covers "THIS HOLE" but presumably not in an air tight manner. – bmike Dec 16 '11 at 23:14
By the way, if you ever build one of those silent oil-submerged computers, DO COVER THIS HOLE! – wim Dec 19 '11 at 2:27
You'll need a snorkel to extend the hole to an uncovered position. – XTL Mar 7 '12 at 12:47
Update in 2018... better to use m.2 SSDs or SATA SSDs in oil-submerged computers nowadays. – Christopher Hostage Apr 24 '18 at 18:17
It allows for equalization of air pressure between the inside and outside of the drive. While it is not a complete pass-through of outside air into the HDD internals, there is a diaphragm filter inside the hole that allows the air pressure to equalize.
If the drive were completely sealed, operating at altitudes significantly different from those the drive was manufactured and sealed at would cause problems and increase the likelihood of catastrophic failures.
This system works in much the same way as the eustachian tubes that allow our ears internal pressures to equalize, preventing the explosion or implosion of our ear drums.
UPDATE: Per Moab's correction, it's a filter, not a diaphragm. The way it works and the reason it is included remains the same.
music2myear
music2myear 37.5k●3434 gold badges●7676 silver badges●120120 bronze badges
Its a filter not a diaphragm, at least on the few hundred I have disassembled. Air actually does move in and out of the hard drive when temps vary. – Moab Dec 16 '11 at 21:07
Here is an excellent teardown of a HDD and a description of how it works (including the filter.) – Andrew Lambert Dec 16 '11 at 22:09
@surfasb I harvest the super magnets out of them, lots of fun for older kids to learn about magnetism, If I was a real nerd I would make some sort of invention out of them. Had a few older drives the platters were made of glass like material, man did they shatter. – Moab Dec 17 '11 at 0:40
@jfgagne I'm not sure your numbers are going the right direction: If pressure decreases, any given volume of air would increase as the altitude rises. Using your 20% number, that would mean that 20cc of air at sea level would be 24cc at "airplane elevation". This is further illustrated by snack bags, which expand at altitude. – music2myear Dec 27 '11 at 14:21
They do make custom HDDs filled with helium which are, by necessity, sealed. Helium has 1/7 the density (thus the drag) of the air which allows thinner plates and air gaps (allowing to fit more plates into a standard-size enclosure) and lower power consumption for spinning the plate stack and positioning the heads. The downside, apart from the stricter external pressure limitations, is the small size of helium molecules that are very hard to keep from sipping outside. – ivan_pozdeev Mar 23 '17 at 19:49
Check out the Wikipedia hard drive entry paying attention to the Integrity section with reference to the "breather hole":
Hard disk drives require a certain range of air pressures in order to operate properly. The connection to the external environment and pressure occurs through a small hole in the enclosure (about 0.5 mm in breadth), usually with a filter on the inside (the breather filter). If the air pressure is too low, then there is not enough lift for the flying head, so the head gets too close to the disk, and there is a risk of head crashes and data loss. Specially manufactured sealed and pressurized disks are needed for reliable high-altitude operation, above about 3,000 m (9,800 ft).[99] Modern disks include temperature sensors and adjust their operation to the operating environment. Breather holes can be seen on all disk drives—they usually have a sticker next to them, warning the user not to cover the holes.
Dennis
Dennis 6,158●2525 silver badges●2828 bronze badges
Ƭᴇcʜιᴇ007
108k●1818 gold badges●185185 silver badges●248248 bronze badges
What happen if the hole is accidentally covered? – deathlock Mar 17 '13 at 11:14
If the harddisk requires a certain air pressure to operate correctly, then why isn't it sealed airtight at the right pressure? Then it would work everywhere (eg: even in a vacuum or high pressure environment). – compie May 15 '14 at 14:28
@compie the pressure difference would deform the enclosure which for such a high-precision device would mean certain malfunction. Instead, for cost efficiency, they make rugged reinforced cases for such applications. – ivan_pozdeev Mar 23 '17 at 19:43
It allows for equalization of air pressure between the inside and outside of the drive. In other words, it keeps the air pressure at the same pressure as atmospheric pressure.
A hard drive is only designed for a certain range of operating pressures. The read/write head floats above the platter on a cushion of air. If the air pressure is too low, then there is not enough lift for the flying head so the head gets too close to the disk and there is a risk of head crashes and data loss.
If the air pressure should be kept constant, why make a hole that allows the air pressure to change?
The hard drive can be used in a range of environments with different temperatures, including ambient temperature and operating temperature. If the drive was completely sealed, the temperature differences would cause large pressure variations in the hard drive. The variation in atmospheric pressure is relatively small compared to these differences.
Also, if the hole was blocked, the pressures could cause the case to bend and the spindle and arm to go out of alignment (theoretically; hard drives look quite solid).
There is another consideration: The hard drive may not be completely air tight apart from the hole, although I'm not sure whether actual hard drives are built this way. In this situation, the hole acts as an easier pathway for air to flow so that the air flows through the filter rather than through unfiltered cracks that allow dust to enter the hard drive.
The above being said, sealed hard drives exist, which have mechanisms to deal with the pressure changes.
Note about the discussion in the other answer: If the drive were completely sealed, operating at altitudes significantly different from those the drive was manufactured and sealed at would have no effect at all (at the same temperature) because the hard drive is a fixed volume so the internal air pressure is unchanged.
user868538
user868538 43●66 bronze badges
Part of this answer appears to be an unsourced direct quote from wikipedia (assuming the other answer that does attribute it is correct). Please properly acknowledge your sources. – Ben Voigt Jun 3 '15 at 15:28
The breather hole allows condensation inside the hard drive to escape and it also equalizes the hard drive's internal pressure with the ambient pressure. The hard drive needs it to function properly, so make sure you won't occlude the hole.
The HDD's spindle system relies on air density inside the disk enclosure to support the heads at their proper flying height while the disk rotates. HDDs require a certain range of air densities in order to operate properly. The connection to the external environment and density occurs through a small hole in the enclosure (about 0.5 mm in breadth), usually with a filter on the inside (the breather filter).
If the air density is too low, then there is not enough lift for the flying head, so the head gets too close to the disk, and there is a risk of head crashes and data loss.
Modern disks include temperature sensors and adjust their operation to the operating environment. Breather holes can be seen on all disk drives—they usually have a sticker next to them, warning the user not to cover the holes.
The air inside the operating drive is constantly moving too, being swept in motion by friction with the spinning platters.
kenorb
kenorb 20.3k●2323 gold badges●111111 silver badges●166166 bronze badges
