• Shunt resistors to be connected to PGA 3 and 4 inputs: R75, R76, R77 = 0R • ENU driving GPIO to be changed from PB13 to PA7: R80 = NP, R74 = 0R 4.3 STSPIN830 current limiter The STSPIN830 implements a PWM current limiter. In single shunt topology, the device monitors the motor current through the SNS pin connected to the sensing resistor. Connected Components Workbench is the software of choice for drive configuration. Working with all 4, 5, and 7-series drives as well as the PowerFlex 755T, CCW is capable of advanced drive programming and configuration. Scroll down for downloads and other information.
