Lafayette Radio & TV: One Tube Transceiver [Amat TRX] ID = 976791 268x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model One Tube Transceiver, Lafayette Radio & TV Corp; New York (NY):
Photo courtesy of Bernard O'Connor
Category: Amateur TRX: Transmitter/Receiver (and Transceiver)
Model: One Tube Transceiver - Lafayette Radio & TV Corp; New
Portable set > 8 inch (also usable without mains)
Simple one-tube portable voice transmitter/receiver sold under Lafayette brand. Manufacturer unknown ("Hammarlund" marking on tuning capacitor may simply indicate that this component was supplied by Hammarlund, and may or may not indicate Hammarlund as the maker of the complete unit). Connection on top of unit presumably for antenna. Jacks for external microphone and headphones. Internal compartment for batteries.
Model page created by Thomas Albrecht. See "Data change" for further contributors.
All listed radios etc. from Lafayette Radio & TV Corp; New York (NY)
Here you find 1315 models, 1125 with images and 399 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.

You can't beat this for a simple one tube cw transmitter. 9 parts total, 10 if you add a milliamp meter.


A single dual triode in push pull operation. Cancels all even harmonics too!

Here's one I built using a 6N7 dual triode. This will put out 10 watts.


My original thread on these transmitters. https://forums.qrz.com/index.php?threads/fun-with-dual-triodes.299710/
All the above require a power supply. This one includes it: http://www.qsl.net/wd4nka/TEXTS/50c5f.HTM
