In digital communications, chirp spread spectrum ( CSS ) is a spread spectrum technique that uses wideband linear frequency modulated chirp pulses to encode information. [1] A chirp is a sinusoidal signal whose frequency increases or decreases over time (often with a polynomial expression for the relationship between time and frequency).
As with other spread spectrum methods, chirp spread spectrum uses its entire allocated bandwidth to broadcast a signal, making it robust to channel noise. Further, because the chirps utilize a broad band of the spectrum, chirp spread spectrum is also resistant to multi-path fading even when operating at very low power. However, it is unlike direct-sequence spread spectrum (DSSS) or frequency-hopping spread spectrum (FHSS) in that it does not add any pseudo-random elements to the signal to help distinguish it from noise on the channel, instead relying on the linear nature of the chirp pulse. Additionally, chirp spread spectrum is resistant to the Doppler effect , which is typical in mobile radio applications. [2]
Chirp spread spectrum was originally designed to compete with ultra-wideband for precision ranging and low-rate wireless networks in the 2.45 GHz band. However, since the release of IEEE 802.15.4a (also known as IEEE 802.15.4a-2007), it is no longer actively being considered by the IEEE for standardization in the area of precision ranging.
Chirp spread spectrum is ideal for applications requiring low power usage and needing relatively low data rates (1 Mbit/s or less). In particular, IEEE 802.15.4a specifies CSS as a technique for use in low-rate wireless personal area networks (LR-WPAN). However, whereas IEEE 802.15.4-2006 standard specifies that WPANs encompass an area of 10 m or less, IEEE 802.15.4a-2007, specifies CSS as a physical layer to be used when longer ranges and devices moving at high speeds are part of your network. Nanotron's CSS implementation was actually seen to work at a range of 570 meters between devices. [3] Further, Nanotron's implementation can work at data rates of up to 2 Mbit/s - higher than specified in 802.15.4a. [4] Finally, the IEEE 802.15.4a PHY standard actually mixes CSS encoding techniques with differential phase shift keying modulation (DPSK) to achieve better data rates.
Chirp spread spectrum may also be used in the future for military applications as it is very difficult to detect and intercept when operating at low power. [5]
Very similar frequency swept waveforms are used in frequency modulated continuous wave radars to measure range (distance); an unmodulated continuous wave Doppler radar can only measure range-rate (relative velocity along the line of sight). FM-CW radars are very widely used as radio altimeters in aircraft.
One application of chirp spread spectrum is LoRa . [6]
All Books Conferences Courses Journals & Magazines Standards Authors Citations
Long range low power is a family of technologies promising to connect thousands of sensors to the future internet of things. Within this family of possible technology choices, two different branches have emerged: the standards based on spreaded wideband communication and the standards based on narrowband communication, both promising to reach long range connectivity at very low power. More specifically, this paper focuses on chirp spread spectrum (CSS). This paper presents a detailed model of CSS, showing that the symbols are not perfectly orthogonal. The results show the potential communication ranges are close to narrowband networks and the robustness against interfering signals is 22 dB better for spreading factor 10 than BPSK. Although wideband communication is robust to interference, in long range communication, this robustness is insufficient due to the long range and the larger footprint. The large propagation losses due to the long range and the larger footprint make CSS prone to collisions with other noise sources, possibly larger than the coding gain.
Date of Conference: 22-22 Nov. 2016
Date Added to IEEE Xplore : 29 December 2016
Conference Location: Mons, Belgium
References is not available for this document.
Long range communication or low power wide area networks (LPWANs) are networks where high data rate requirements are traded for range and energy improvements. In these networks, data rates are very low, leaving hardly a few bytes per seconds, but enabling ranges of a few kilometers. In our previous paper [1], we have compared two such LPWANs: an ultra narrowband, Sigfox-like standard with a wideband, LoRa-like technology. This paper elaborates more on our detailed model of the physical layer of CSS and prove that the spreading factors are not perfectly orthogonal.
